FOR CLEAN LED lamps to be fitted in lightweight metal suspended ceiling LP2 107.03/A
LED fixtures are used for the lighting of interiors with basic environment. They are mostly flush-mounted in the lightweight metal suspended ceiling /LP/ For Clean, a.s. The light fixture features IP 44 ingress protection from the top and IP 54 ingress protection from the bottom according to EN 60529 (IEC 529).
TECHNICAL DATA
| Section in project documentation |
|---|
| snap-on FOR CLEAN LED fixtures to be fitted in lightweight metal suspended ceiling LP2 |
| Grid dimensions x light fixture height |
|---|
| 312x1250x33 |
| 312x625x33 |
| 625x625x33 |
| Backup power source / light fixture |
|---|
| standard light fixture - without backup power source |
| standard light fixture + emergency lighting kit HELP2 |
| Dimmable light fixture |
|---|
| standard light fixture (non-dimmable) |
| dimmable light fixture |
| Bottom frame material and colour (RAL) |
|---|
| steel sheet class 11, hue RAL 1015 |
| steel sheet class 11, hue RAL 6027 |
| steel sheet class 11, hue RAL 9002 |
| steel sheet class 11, hue RAL 9016 |
| stainless steel AISI 304 FIN 8 |
| Atypical design |
|---|
| Type design |
| Atypical design |
| Type design 0 - Unique specification out of offered versions Atypical design Q - atypical design that cannot be uniquely specified by a code |
